Installation 2-9
Figure 2.6 Dimensions: 317…480 A Controllers
All dimensions are approximate and are not intended for manufacturing purposes. Consult your
local Allen-Bradley distributor for complete dimension drawings.
Unit
A
Width
B
Height
C
Depth
DEFGHI
Approx.
Ship. Wt.
317…480 A
Controller
mm 290 600 276.5 200 539.18 182.25 104.5 55.5 103.5 45.8 kg
in. 11.42 23.62 10.89 7.87 21.23 7.18 4.11 2.19 4.07 101 lb.
40.9
(1.6)
276.5
(10.89)
6.35
182.25
(7.18)
C
F
63.5
(2.50)
17
(.67)
22.5
(.89)
#8 - 32 UNC - 2B
12.522
(.49)
32.74
(1.29)
48
(1.89)
M12 x 1.75
30.5
(1.20)
