Rockwell Automation SMC-Flex User Manual

Wiring 3-29
Figure 3.27 Typical Slow Speed Wiring Diagram for Hand-Off-Auto (DPI)
Control
➀
Customer supplied.
➁ Slow Speed.
➂ Refer to the controller nameplate to verify the rating of the control power input voltage.
For units rated 625…1250 A, terminals 11 & 12 are factory pre-wired from terminal block
CP1 - terminals 1 & 4.
➃ Aux #4 should be set to normal operation.
11 12
13
14
15 16
17
18 19 20
21
23
24
25 26
27
28 29
30 31 32 33
22
34
L1/1
L3/5
L2/3
T3/6
T2/4
T1/2
M
3-Phase
Input Power
Branch
Protection
SMC-Flex
Controller
H A
Aux #3Aux #2
Aux #4
Aux #1
SMC-Flex
Control Terminals
Option Command
Hand Start
Hand Stop
PTC
Input
TACH
Input
Ground
Fault
➀
➀
➀
➀
➀
➀
➀➁
➂
➀
➀
➃
