4-4 Programming
Table 4.A Parameter Linear List
Parameter No. Description Parameter No. Description Parameter No. Description
1 Volts Phase A-B 49 OL Trip Enable/Disable 97 Data Out A2
2 Volts Phase B-C 50 Overload A Lvl 98 Data Out B1
3 Volts Phase C-A 51 Underload F Lvl 99 Data Out B2
4 Current Phase A 52 Underload F Dly 100 Data Out C1
5 Current Phase B 53 Underload A Lvl 101 Data Out C2
6 Current Phase C 54 Underload A Dly 102 Data Out D1
7 Watt Meter 55 Undervolt F Lvl 103 Data Out D2
8 Kilowatt Hours 56 Undervolt F Dly 104 Motor ID
9 Elapsed Time 57 Undervolt A Lvl 105 CT Ratio
10 Meter Reset 58 Undervolt A Dly 106 MV Ratio
11 Power Factor 59 Overvolt F Lvl 107 Aux1 Config
12 Mtr Therm Usage 60 Overvolt F Dly 108 Aux3 Config
13 Motor Speed 61 Overvolt A Lvl 109 Aux4 Config
14 SMC Option 62 Overvolt A Dly 110 Aux2 Config
15 Motor Connection 63 Unbalance F Lvl 111 Language
16 Line Voltage 64 Unbalance F Dly 112 Timed Start
17 Starting Mode 65 Unbalance A Lvl 113 I Shut Off Level
18 Ramp Time 66 Unbalance A Dly 114 UTS Level
19 Initial Torque 67 Jam F Lvl 115 Parameter Mgmt
20 Cur Limit Start 68 Jam F Dly 116 Backspin Timer
21 Reserved 69 Jam A Lvl 117 VShut Off Level
22 Kickstart Time 70 Jam A Dly 118 OL Reset Level
23 Kickstart Level 71 Stall Delay 119 Ambient Temp
24 Option Input 2 72 Gnd Flt Enable 120 Notch Position
25 Starting Mode 2 73 Gnd Flt Level 121 Notch Maximum
26 Ramp Time 2 74 Gnd Flt Delay 122 Start Delay
27 Initial Torque 2 75 Gnd Flt Inh time 123 By-pass Delay
28 Cur Limit Level 2 76 Gnd Flt A Enable 124 Fault 1
29 Reserved 77 Gnd Flt A Level 125 Fault 2
30 Kickstart Time 2 78 Gnd Flt A Delay 126 Fault 3
31 Kickstart Level 2 79 PTC Enable 127 Fault 4
32 Stop Mode 80 Phase Reversal 128 Fault 5
33 Stop Time 81 Start Per Hour 129 Ramp Time E
34 Pump Pedestal 82 Restart Attempts 130 Ramp Time 2E
35 Braking Current 83 Restart Delay 131 Stop Time E
36 Braking Time 84 Line Fault Disable 132 Option Input 1
37 Load Type 85 Emergency Run 133 Stop Input
38 High Eff Brake 86 Current Loss 134 Elapsed Time 2
39 Slow Speed Sel 87 Logic Mask
40 Slow Speed Dir 88 Data In A1
41 Slow Accel Cur 89 Data In A2
42 Slow Running Cur 90 Data In B1
43 Stopping Current 91 Data In B2
44 Overload Class 92 Data In C1
45 Service Factor 93 Data In C2
46 Motor FLC 94 Data In D1
47 Overload Reset 95 Data In D2
48 OL Shunt Time 96 Data Out A1
