Roland Octa-Capture User Manual

15
Windows 7/Windows Vista Users
Installing the Driver
Steps to be performed on the OCTA-CAPTURE keyboard itself are marked by a
Operation of the OCTA-CAPTURE
symbol. Don’t connect the OCTA-CAPTURE to your computer
until you are told to do so.
* The example screen shots included here are taken from Windows 7.
1. With the OCTA-CAPTURE disconnected, start up Windows.
Disconnect all USB cables from your computer, with the exception of those for a USB keyboard and
USB mouse (if used).
2. Close all currently running software.
3. Insert the included OCTA-CAPTURE CD-ROM into your DVD-ROM drive.
When the auto-play dialog box appears, click [Open folder to view les].
4. In the appropriate folder within the CD-ROM, double-click the [Setup] icon to start up
the installer.
OS Installer
Windows 7: Open the folders [Driver] and then [Win7]
Windows Vista: Open the folders [Driver] and then [Vista]
Windows 7 64-bit edition: Open the folders [x64Driver] and then [Win7]
Windows Vista 64-bit edition: Open the folders [x64Driver] and then [Vista]
If you get a message saying “The operating system you are using is not supported” or “The version
of this le is not compatible with the version of Windows you’re running,” or if you don’t know the
version of your operating system, check your operating system as described below.
If “System type” indicates “64-bit Operating System,” you have the 64-bit version.
Windows 7 users
Open “Control Panel,” click “System and Security,” and then click [System].
If the Control Panel shows the icon view, click [System] icon.
Windows Vista users
Open “Control Panel,” click [System and Maintenance], and then click [System].
If the Control Panel shows the classic view, double-click the “System” icon.

Roland Octa-Capture Specifications

Audio Channels

number of audio record channels (44.1/48/96 kHz)	12 channels
number of audio playback channels (44.1/48/96 kHz)	10 channels
number of audio record channels (192 kHz)	4 channels
number of audio playback channels (192 kHz)	4 channels

Signal Processing

pc interface bit depth	24-bit
ad/da conversion bit depth	24-bit
internal processing bit depth	40-bit

Sampling Frequency

ad/da conversion sampling frequency	44.1/48/96/192 kHz
digital (in/out) sampling frequency	44.1/48/96 kHz

Input and Output Levels

nominal input level (input jack 1-6, xlr type)	-56 to -6 dBu
nominal input level (input jack 7-8, xlr type)	-50 to +0 dBu
nominal input level (input jack 1-8, 1/4-inch trs phone type)	-46 to +4 dBu
nominal output level (output 1-8)	+0 dBu (balanced)
headroom	16 dB

Impedance

input impedance (input jack 1-6, xlr type)	5 k ohms (balanced)
input impedance (input jack 7-8, xlr type)	10 k ohms (balanced)
input impedance (input jack 1-8, 1/4-inch trs phone type)	17 k ohms (balanced)
output impedance (output 1-8)	1.8 k ohms (balanced)
output impedance (phones)	47 ohms

Frequency and Noise

frequency response (192 kHz)	20 Hz to 90 kHz (+0/-8 dB)
frequency response (96 kHz)	20 Hz to 40 kHz (+0/-2 dB)
frequency response (48 kHz)	20 Hz to 22 kHz (+0/-2 dB)
frequency response (44.1 kHz)	20 Hz to 20 kHz (+0/-2 dB)
residual noise level	-87 dBu typ. (GAIN: min., 600 ohms terminated, IHF-A)

Dynamic Range and Display

dynamic range (ad block input 1-8)	104 dB typ. (GAIN: min.)
dynamic range (da block output 1-8)	113 dB typ.
display	128 x 64 dots Graphic LCD (backlit LCD)

Connectors

input jacks (xlr type / 1/4-inch trs phone type)	XLR type (balanced/phantom power +48 V), 1/4-inch TRS phone type (balanced)
coaxial input connector	present
coaxial output connector	present
headphone jack	Stereo 1/4-inch phone type
output jack (1/4-inch trs phone type)	balanced
midi connectors	In, Out
usb connector	present

Power and Dimensions

power supply	DC 9 V (AC adaptor)
current draw	1.45 A
dimensions	283.8 (W) x 157.9 (D) x 50.4 (H) mm / 11-3/16 (W) x 6-1/4 (D) x 2 (H) inches
weight	1.32 kg / 2 lbs 15 oz
