Page #77 background imageLoading...
Page #77 background image
77
System “Performance Settings (Windows)
If you experience problems such as interrupted notes or dropouts in the sound, you may be able to
solve the problem by changing the “Performance setting of the system as described below.
Windows 7 users
1. Open the Control Panel, click [System and Security], and click [System].
If you’re using an icon display, double-click the [System] icon.
2. At the left, click [Advanced system settings].
3. A User Account Control dialog box will appear; click [Yes].
If you’re asked to enter an administrator password, log on to Windows as a user whose account type
is administrator, and make the setting again.
4. Click [Settings] of the Performance section, and click the [Advanced] tab.
5. Choose [Background services] and click [OK].
6. Click [OK] to close “System Properties.
Windows Vista users
1. Open the Control Panel, click [System and Maintenance], and click [System].
* If you’re using the Classic view, double-click the [System] icon.
2. In the list of “tasks” shown at the left, click [Advanced System Settings].
3. A User Account Control dialog box will appear; click [Continue].
* If you’re asked to enter an administrator password, log on to Windows as a user whose account
type is administrator, and make the setting again.
4. Click [Settings] of the Performance section, and click the [Advanced] tab.
5. Choose [Background services] and click [OK].
6. Click [OK] to close System Properties.
Windows XP users
1. Open the Control Panel, click [Performance and Maintenance], and click [System].
* If you’re using the Classic view, double-click the [System] icon.
2. Click the [Advanced] tab, and click [Settings] in “Performance.
3. Click the [Advanced] tab.
4. Choose [Background services], and click [OK].
5. Click [OK] to close “System Properties.

Table of Contents

Other manuals for Roland Octa-Capture

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Roland Octa-Capture and is the answer not in the manual?

Roland Octa-Capture Specifications

Audio Channels IconAudio Channels
number of audio record channels (44.1/48/96 kHz)12 channels
number of audio playback channels (44.1/48/96 kHz)10 channels
number of audio record channels (192 kHz)4 channels
number of audio playback channels (192 kHz)4 channels
Signal Processing IconSignal Processing
pc interface bit depth24-bit
ad/da conversion bit depth24-bit
internal processing bit depth40-bit
Sampling Frequency IconSampling Frequency
ad/da conversion sampling frequency44.1/48/96/192 kHz
digital (in/out) sampling frequency44.1/48/96 kHz
Input and Output Levels IconInput and Output Levels
nominal input level (input jack 1-6, xlr type)-56 to -6 dBu
nominal input level (input jack 7-8, xlr type)-50 to +0 dBu
nominal input level (input jack 1-8, 1/4-inch trs phone type)-46 to +4 dBu
nominal output level (output 1-8)+0 dBu (balanced)
headroom16 dB
Impedance IconImpedance
input impedance (input jack 1-6, xlr type)5 k ohms (balanced)
input impedance (input jack 7-8, xlr type)10 k ohms (balanced)
input impedance (input jack 1-8, 1/4-inch trs phone type)17 k ohms (balanced)
output impedance (output 1-8)1.8 k ohms (balanced)
output impedance (phones)47 ohms
Frequency and Noise IconFrequency and Noise
frequency response (192 kHz)20 Hz to 90 kHz (+0/-8 dB)
frequency response (96 kHz)20 Hz to 40 kHz (+0/-2 dB)
frequency response (48 kHz)20 Hz to 22 kHz (+0/-2 dB)
frequency response (44.1 kHz)20 Hz to 20 kHz (+0/-2 dB)
residual noise level-87 dBu typ. (GAIN: min., 600 ohms terminated, IHF-A)
Dynamic Range and Display IconDynamic Range and Display
dynamic range (ad block input 1-8)104 dB typ. (GAIN: min.)
dynamic range (da block output 1-8)113 dB typ.
display128 x 64 dots Graphic LCD (backlit LCD)
Connectors IconConnectors
input jacks (xlr type / 1/4-inch trs phone type)XLR type (balanced/phantom power +48 V), 1/4-inch TRS phone type (balanced)
coaxial input connectorpresent
coaxial output connectorpresent
headphone jackStereo 1/4-inch phone type
output jack (1/4-inch trs phone type)balanced
midi connectorsIn, Out
usb connectorpresent
Power and Dimensions IconPower and Dimensions
power supplyDC 9 V (AC adaptor)
current draw1.45 A
dimensions283.8 (W) x 157.9 (D) x 50.4 (H) mm / 11-3/16 (W) x 6-1/4 (D) x 2 (H) inches
weight1.32 kg / 2 lbs 15 oz
