124
Chapter 8: Specifications
8-1 Media Conditions
Usable Media
Use genuine media from Roland DG Corp.
Media width
8-5/16 to 54 inches (210 to 1371 mm)
A) Cuttable media thickness
0.08 to 0.22 mm (3.2 to 8.6 mil)
(depending on media composition)
B) Maximum media thickness (including backing paper)
Printing only : 1.0 mm (39 mil)
When performing cutting : 0.4 mm (15 mil)
C) Maximum diameter for roll media
180 mm
D) Paper tube (core) inner diameter
50.8 mm or 73.2 mm (2 inches or 3 inches)
Maximum weight for roll media
20 kg (44 lb.)
Other conditions
Media such as the following cannot be used.
• Media having an inward curl (i.e., media whose print surface is on the inner side of the roll)
• Media whose end is attached to the paper pipe (core)
• Media which is severely warped or which has a strong tendency to reroll
• Media that cannot withstand the heat of the print heater
• Media whose paper pipe (core) is bent or crushed
C
D
AB
