Chapter 1: Getting Started
1-3 Assembling and Installing
Step 1: Assemble the Stand
First assemble the stand, then mount the machine on top of the stand.
1
Invert the stand legs as shown in the figure. While supporting the stand legs with your hand, attach the
left- and right-hand casters.
2
Set the stand upright so that the casters are at the bottom, and place the machine on the stand.
The front and rear of the stand are as shown in the figure.
Tighten the bolts securely. Loose bolts may cause the stand to wobble.
4 pcs.
4 pcs.
Pipe
Short
Long
Bolts (Large)
Hexagonal wrench
Front
Line up the frame at the
back of the machine with
the fixtures on the stand.
