129
Chapter 8: Specifications
8-5 Locations of the Power Rating and Serial Number Labels
Serial Number
This is require when you seek maintenance,
servicing, or support. Never peel off the la-
bel or let it get dirty
.
Power Rating
Use an electrical outlet that meets the re-
quirements for voltage, frequency
, and am-
perage given here.
130
132
