44
Chapter 2: Basic Operation
10
Close the front cover.
Use the [ ] and [ ] keys to select [ROLL],
then press the [ENTER] key.
11
Press the [SETUP] key.
This detects the width of the media and displays the print-
able width.
If a pinch roller is positioned over an area where is no
grit roller, the message shown at below appears when
you press the [SETUP] key. Check the positioning of
the pinch rollers and make sure they are aligned at the
correct positions.
W 1234 mm
Top menu
PINCHROLL ERROR
INVALID LEFT POS
SETUP SHEET
ROLL
If cutting is to be performed from the edge of the media, select [EDGE] (If [EDGE] does not appear, set [EDGE SENSE]
to [ENABLE]).
The SETUP LED lights up
or [RIGHT]
When the machine will remain unused for an extended period, remove roll media from the machine and store it.
If roll media is left mounted on the machine for an extended period, these entire roll may warp, resulting in poor printed image
quality or motor errors.
2-3 Loading Media
