106
Appendices
Computer Cable Wiring Diagrams
fig.11-5e
67
8
34
5
12
67
8
34
5
12
67
8
34
5
12
mini DIN, 8-pin, male
mini DIN, 8-pin, male
mini DIN, 8-pin, male
D-sub, 25-pin, female
mini DIN, 8-pin, male
mini DIN, 8-pin, male
1 HSKo
2 HSKi
3 TXD-
4 GND
5 RXD-
6 TXD+
7 GPi
8 RXD+
HSKo 1
HSKi 2
TXD- 3
GND 4
RXD- 5
TXD+ 6
GPi 7
RXD+ 8
67
8
34
5
12
mini DIN, 8-pin, male
D-sub, 9-pin, female
mini DIN, 8-pin, male
D-sub, 9-pin, female
HSKo 1
HSKi 2
TXD- 3
GND 4
RXD- 5
7 RTS
8 CTS
3 TXD
5 GND
2 RXD
51
96
13
1
25
14
For Apple Macintosh (Sold separately: RSC-15APL)
For PC (9-pin) (Sold separately: RSC-15AT)
For PC (25-pin)
mini DIN, 8-pin, male
D-sub, 25-pin, female
HSKo 1
HSKi 2
TXD- 3
GND 4
RXD- 5
4 RTS
5 CTS
2 TXD
7 GND
3 RXD
105
