174
Appendices
■Parameter address map
This map indicates address, size, Data (range), Parameter, Description, and Default Value of parameters which can be transferred using “Request data 1 (RQ1)” and “Data set 1 (DT1)”. All the
numbers of address, size, Data, and Default Value are indicated in 7-bit Hexadecimal-form. Numbers in the explanatory column are given in decimal notation. The MODEL ID = 45H parameters
are related to LCD display.
●System Parameters
Parameters affecting the entire unit are called System Parameters.
<MODEL ID = 42H>
Address(H) Size(H) Data(H) Parameter Description Default(H) Description
00 00 7F 00 00 01 00 – 01 SYSTEM MODE SET 00 MODE-1
00: MODE-1 (Single module mode)
(Rx. only)
* When the Data value 00 is received, the same processing will be carried out as when GS Reset is received. Other values are ignored.
CHANNEL MSG RX PORT
00 01 00 00 00 01 00 – 03 BLOCK00 PORT A, B 00 PORT A
: : : : :
00 01 0F 00 00 01 00 – 03 BLOCK0F PORT A, B 00 PORT A
00 01 10 00 00 01 00 – 03 BLOCK10 PORT A, B 01 PORT B
: : : : :
00 01 1F 00 00 01 00 – 03 BLOCK1F PORT A, B 01 PORT B
* You can modify the receiving MIDI port at which channel messages will be received for each BLOCK. We suggest that normally you use PORT A for BLOCK00 – 0F, PORT B for BLOCK10 –
1F. (In this case there is no need to change the setting.)
* Refer to page 176 for details of each BLOCK.
●Patch parameters
❍Patch common parameters
The parameters common to all Parts in each module are called Patch Common parameters.
Address(H) Size(H) Data(H) Parameter Description Default Value (H) Description
40 00 00 00 00 04 0018 – 07E8 MASTER TUNE -100.0 – +100.0 [cents] 00 04 00 00 0 [cents]
40 00 01# Use nibblized data.
40 00 02#
40 00 03#
* Refer to section 5. Supplementary material, About the Tuning (page 184).
40 00 04 00 00 01 00 – 7F MASTER VOLUME 0 – 127 7F 127
(= F0 7F 7F 04 01 00 vv F7)
40 00 05 00 00 01 28 – 58 MASTER KEY-SHIFT -24 – +24 [semitones] 40 0 [semitones]
40 00 06 00 00 01 01 – 7F MASTER PAN -63 (LEFT) – +63 (RIGHT) 40 0 (CENTER)
40 00 7F 00 00 01 00 MODE SET 00 = GS Reset
(Rx. only)
40 01 00 00 00 10 20 – 7F PATCH NAME 16 ASCII Characters
40 01 : #
40 01 0F#
40 01 30 00 00 01 00 – 07 REVERB MACRO 00: Room 1 04 Hall 2
01: Room 2
02: Room 3
03: Hall 1
04: Hall 2
05: Plate
06: Delay
07: Panning Delay
40 01 31 00 00 01 00 – 07 REVERB CHARACTER 0 – 704 4
40 01 32 00 00 01 00 – 07 REVERB PRE-LPF 0 – 700 0
40 01 33 00 00 01 00 – 7F REVERB LEVEL 0 – 127 40 64
40 01 34 00 00 01 00 – 7F REVERB TIME 0 – 127 40 64
40 01 35 00 00 01 00 – 7F REVERB DELAY FEEDBACK 0 – 127 00 0
40 01 37 00 00 01 00 – 7F REVERB PREDELAY TIME 0 – 127 [ms] 00 0
* REVERB MACRO is a macro parameter that allows global setting of reverb parameters. When you select the reverb type with REVERB MACRO, each reverb parameter will be set to their most
suitable value.
* REVERB CHARACTER is a parameter that changes the reverb algorithm. The value of REVERB CHARACTER corresponds to the REVERB MACRO of the same number.
To Next Page
