30
Parameters
❏ KEYBOARD RANGE LOW (Keyboard Range Low) C-1–G9
❏ KEYBOARD RANGE HIGH (Keyboard Range High) C-1–G9
The Key Range parameters determine the pitch range over which the instrument will
be sounded. Keyboard Range Low (the lowest note) and Keyboard Range High (the
highest note) will determine the range of notes that will sound. These values are dis-
played as key names. You can specify a value between C-1 and G9 (0–127), and mid-
dle C is C4 (60).
fig.5-6e
For example, if you assign two Parts to the same MIDI channel and set the Keyboard
Range of one to C-1–B3 and the other to C4–G9. Then you could assign different
sounds to each Part, and play two different sounds on either side of C4. Or, you
could set the keyboard ranges of two Parts to overlap, and layer the two sounds.
fig.5-7e
❏ CC1 CONTROLLER NUMBER (CC1 Controller Number) 0–16–95
Set the Controller number that will control the CC1 parameters (p.32) via MIDI. For
example, if you set CC1 Controller Number to 16, the value of an incoming MIDI
Controller number 16 message will affect the sound as specified by the setting of the
CC1 parameter.
C1 C2 C3 C4 C5 C6 C7 C8
A0C-1 G9
24 36 48 60 72 84 96 108
210 127
Note Name
MIDI Note Number
C4
B3
Instrument 1 Instrument 2
Be aware that if Keyboard
Range High is set to a note
name lower than Keyboard
Range Low, there will be
no sound.
