76
Effects
● EQ (Equalizer)
EQ L Gain (EQ Low Gain) -12–+12 [10 (40 03 0C)]
Adjusts the low-range gain of the equalizer.
EQ M Fq (EQ Mid Frequency) 200–6.3k [11 (40 03 0D)]
Sets the center frequency for the equalizer mid-range.
EQ M Q (EQ Mid Q) 0.5/1.0/2.0/4.0/9.0 [12 (40 03 0E)]
Adjusts the width of the area centered at the EQ M Fq
setting in which the gain will be affected. The area affected
will become narrower as this value is increased.
EQ M Gain (EQ Mid Gain) -12–+12 [13 (40 03 0F)]
Adjusts the gain of the area specified by the EQ M Fq
parameter and the EQ M Q parameter.
EQ H Gain (EQ High Gain) -12–+12 [14 (40 03 10)]
Adjusts the high-range gain of the equalizer.
● CF (Chorus/Flanger)
CF Sel (CF Select) Chorus/Flangr [15 (40 03 11)]
Selects either Chorus or Flanger.
CF Rate 0.05–6.40 [16 (40 03 12)]
Adjusts the speed of modulation for the chorus or flanger.
CF Depth 0–127 [17 (40 03 13)]
Adjusts the depth of modulation for the chorus or flanger.
CF Fb (CF Feedback Level) -98%–+98% [18 (40 03 14)]
Adjusts the amount (%) of the flanger sound that will be
returned to the input. Negative (-) values will invert the
phase.
* In the case of Chorus, this will have no effect.
#CF Mix 0–127 [19 (40 03 15)]
Adjusts the volume of the chorus or flanger sound.
Level (Output Level) 0–127 [20 (40 03 16)]
Adjusts the output level.
54: Rhodes Multi [04H, 06H]
Rhodes Multi provides Enhancer (EH), Phaser (PH), Chorus
or Flanger (CF), and Tremolo or Pan (TP) effects connected in
series.
fig.9-57
● EH (Enhancer)
EH Sens (Enhancer Sensitivity) 0–127 [1 (40 03 03)]
Adjusts the sensitivity of the enhancer.
EH Mix (Enhancer Mix Level) 0–127 [2 (40 03 04)]
Adjusts the level at which the overtones generated by the
enhancer will be mixed with the direct sound.
● PH (Phaser)
PH Man (Phaser Manual) 100–8.0k [3 (40 03 05)]
Adjusts the center frequency at which the sound will be
modulated.
PH Rate (Phaser Rate) 0.05–6.40 [4 (40 03 06)]
Adjusts the modulation speed.
PH Depth (Phaser Depth) 0–127 [5 (40 03 07)]
Adjusts the modulation depth.
PH Reso (Phaser Resonance) 0–127 [6 (40 03 08)]
Adjusts the emphasis for the region around the center
frequency specified by the PH Man parameter.
PH Mix (Phaser Mix) 0–127 [7 (40 03 09)]
Adjusts the proportion of the phase-shifted sound that will
be mixed with the direct sound.
● CF (Chorus/Flanger)
CF Sel (CF Select) Chorus/Flangr [8 (40 03 0A)]
Selects either Chorus or Flanger.
CF LPF (CF Low Pass Filter)
250–6.3k/Bypass [9 (40 03 0B)]
Cuts the high frequency range of the chorus or flanger
sound.
CF Dly (CF Pre Delay) 0–100ms [10 (40 03 0C)]
Adjusts the time from the direct sound until when the
chorus or flanger sound is heard.
CF Rate 0.05–6.40 [11 (40 03 0D)]
Adjusts the modulation speed.
CF Depth 0–127 [12 (40 03 0E)]
Adjusts the modulation depth.
CF Fb (CF Feedback Level) -98%–+98% [13 (40 03 0F)]
Adjusts the amount (%) of the flanger sound that will be
returned to the input. Negative (-) values will invert the
phase.
* In the case of Chorus, this will have no effect.
CF Mix 0–127 [14 (40 03 10)]
Adjusts the volume of the chorus or flanger sound.
● TP (Tremolo/Pan)
TP Sel (TP Select) Trem/Pan [15 (40 03 11)]
Selects either Tremolo or Pan.
TP Mod WV (TP Modulation Wave)
Tri/Sqr/Sin/Saw1/Saw2 [16 (40 03 12)]
Selects the way in which tremolo or pan will be modulated.
Tri: The sound will be modulated like a triangle
wave.
Sqr: The sound will be modulated like a square
wave.
Sin: The sound will be modulated like a sine
wave.
Saw1,2: The sound will be modulated like a
sawtooth wave.
L
R
CFPH
EH
EH
TP
TP
