Product Specification
Quantum Intelligent EV Charging Pedestal EVQM-V01-R6 Installation and Operation Manual
Page 11 of 52 December 2023
User Interface
x Mobile app
x RFID
sensor (Mifare ISO/IEC 14443 A)
x Plug & charge
x RGB LED status indicator halo(s) – configurable
Charge Protocol Mode 3 (IEC 61851-1)
Protection
x AC overload & fault current protection – 40A 30mA Type-A RCBO (per socket)
x DC fault protection – 6mA
x Lightning surge, over temperature protection
x TruePEN PME fault detection – No earth electrode/rod required
x Supports automatic dynamic load balancing (may require additional hardware)
x Supports static load management (software configurable)
Cable Terminals
x Single Phase – 3x 50mm 1P + N + E
(2x [3x 50mm] for ROLEC0425B, ROLEC0425G, ROLEC0425W. (Alternative cable terminals
available upon request)
x Three Phase – 5x 50mm 3P + N + E
Communications
x 4G LTE Cat-1 (built-in nano SIM, subscription required)
x LTE FDD: B1/B3/B5/B7/B8/B20/B28
x GSM: B2/B3/B5/B8
x Wi-Fi 802.11 b/g/n 2.4 GHz (2412-2472 MHz / 2422-2462 MHz)
x NFC 13.56 MHz
x RJ45 Ethernet connection
x Bluetooth Low Energy (BLE 4.1) 2402-2480 MHz (for installer configuration purposes)
x OCPP 1.6J
x Cyber security – Data encryption level TLS 1.2
Energy Metering Integrated Class 1 MID compliant metering
Amenity Lighting
x 360° Low energy LED
x Rating – 1 x GX53 LED, 9W, 230-240V AC
x Colour temperature – 4000K
x Protection – 6A 30mA Type-A RCBO
Standby Power
Consumption
< 7.5W (per socket, excludes amenity lighting)
Dimensions 375mm x 1440mm x 275mm (W x H x D)
Weight < 32kg (model dependant)
Environmental
x Ingress protection – Enclosure IP66, Socket IP54
x Impact protection – IK10
x Security – Dual tamper & breach notifications (optional in some units)
x Operating temperature – -30°C to +50°C
x Operating humidity – 5% to 95%
Materials
x Substructure – 2.5mm 6063 extruded Aluminium, 25 micron hard anodised protective finish
x Panel – 3.2mm Aluminium composite
x Lens – High impact resistant 3mm polycarbonate
x Base – High impact resistant, heavy-duty 5mm polycarbonate
x Lid/collar/louvres – High impact resistant polycarbonate
Unit Colour Black, Grey or White (Other colours available upon request)
Certifications &
Compliances
x EV Charging Compliance – EN 61851-1:2019, EN 61851-22:2002
x Smart Charge Points – (SI 2021/1467) (Pre 2023 units may exclude Schedule 1)
x Wiring Regulations – BS 7671:2018+A2:2022
x EMC Compliance – EN 61000-6-3:2007+A1:2011, EN 61000-6-2:2005, 2014/30 /EU, SI 2016/1091
x Safety Compliance (LVD) – EN 62368-1:2014, 2014/35/EU, SI 2016/1101
x 30 mA AC & 6 mA DC Protection – in accordance with IEC EN 61009-1:2012+A12:2016,
IEC61009-2-1:1994+A11:1998, BS IEC 62955:2018
x Communications / RED – EN 62311:2008, 2014/53/EU, SI 2017/1206,
EN 300 330 V2.1.1 (2017-02), EN 301 908-1 V15.1.1 (2021-09),
EN 301 908-13 V13.2.1 (2022-02), EN 301 511 V12.5.1 (2017-03),
EN 300 328 V2.2.2 (2019-07), EN 300 440 V2.2.1 (2018-07).
x Environmental Protection – BS EN 60529:1992+A2:2013
x Impact Rating – BS EN 62262:2002+A1:2021
x Metering – 2014/32/EU, SI 2016/1153
x RoHS – 2011/65/EU, SI 2012/3032
x REACH – 1907/2006, REACH etc. (Amendment) Regulations 2021
x Certification Markings – CE & UKCA
Warranty 3 years
Rolec Services Ltd are a registered manufacturer (WEE/AG3499TY) within the WEEE Recycling Scheme, allowing its products
at the end of their life, to be processed by an appropriate local service provider.
