Installation
EVQM-V01-R6 Installation and Operation Manual Quantum Intelligent EV Charging Pedestal
December 2023 Page 22 of 52
NOTE: All electrical work must be performed in accordance with the current
legislation applicable in the geographical region of the installation.
CAUTION; Equipment Damage – Sensitive Equipment
If you will be performing insulation resistance tests on the power supply cables, it is
advised to be done BEFORE connecting the cable to the chargepoint. The high
voltages applied during the test may damage sensitive components if tested after
the cable is connected.
8. If required, install the optional Load Balancing system, refer to page 22 Install Load
Balancing shown immediately after these ‘standard’ installation instructions.
9. When Load Balancing has been installed, return to this point.
10. Route the incoming cables through the pedestal, ready to connect to the
appropriate terminals within the enclosure.
11. Terminate the supply cable in the appropriate manner and connect it to the
pedestal.
12. If required, connect the Ethernet cable to the Smart Communications Module.
13. Make sure ALL debris is removed from the enclosure and that no debris is present
on any of the components.
NOTE: Debris and similar pollutants can adversely affect the performance and
working life expectancy of components and will invalidate the product/component
warranty.
IMPORTANT:
It is the responsibility of the installation engineer to satisfy themselves, that all
accessible cable terminations throughout this product are secure and have not
become loose, strained, or disconnected during transit and/or installation.
14. Make sure all cable connections are secure and have not become loose or
damaged in transit or during installation.
15. Switch ON the power to the chargepoint and test in accordance with the current
legislation applicable in the geographical region of the installation.
16. Make sure you are satisfied that the electrical installation is complete then, If
required, temporarily close the chargepoint enclosure for safety and security.
Access to the components will be needed during the configuration process.
Install Load Balancing
NOTE: This manual assumes the installation of a single chargepoint. Whilst multiple
chargepoints can be connected in a similar way, installers may wish to consider
connecting/monitoring via third-party equipment.
If connecting/monitoring via third-party equipment, make sure you are fully aware of
the manufacturer’s instructions so that the device/system can be installed correctly and
in conjunction with the chargepoint installation.
If load balancing will be enabled on this chargepoint it should, ideally, be installed
alongside the ‘standard installation’.
