Unpacking
EVQM-V01-R6 Installation and Operation Manual Quantum Intelligent EV Charging Pedestal
December 2023 Page 12 of 52
Unpacking
IMPORTANT: Make sure all packaging is disposed of responsibly and in accordance with
the current regulations in your region.
Standard Contents
x EV Chargepoint
x Rolec ‘EV Connect’ Configuration Tag
x Rubber Mat
x Installation and Operation Manual
1. Examine the package and make sure the contents have not been damaged in
transit.
2. Make sure the chargepoint model and any accessories match the order.
3. Do NOT dispose of the packaging until the chargepoint has been installed and is
working correctly.
x Please dispose of packaging responsibly when it is appropriate to do so.
NOTE: Items damaged in transit must first be reported to the courier and then to the
supplier. Where possible, photographic evidence of package and/or unit damage
should be supplied.
NOTE: Incorrect or damaged units must NOT be installed. Contact your supplier to
discuss rectification.
Options and Accessories
Product Code Item Description
RFID0010 RFID card
RFID0020 RFID fob
GMQR0010 Ground mounting base for Quantum pedestal
EVCB0020 Root mount protection barrier – 48mm
EVCB0040 Surface mount protection barrier – 48mm
EVPS0010 EV parking sign – A4 landscape
(Other sizes are available)
EVPP0100 5m 32A Type 2 to Type 2 charging cable
EVPP0107 10m 32A Type 2 to Type 2 charging cable
EVPP0105 5m 32A 3 Phase Type 2 to Type 2 charging cable
EVPP0108 10m 32A 3 Phase Type 2 to Type 2 charging cable
(Other cables are available, including Type 1 options)
ACSR0125 100A, up to 35mm
2
screened CT clamp with 10m cable
