Installation
Quantum Intelligent EV Charging Pedestal EVQM-V01-R6 Installation and Operation Manual
Page 15 of 52 December 2023
4. Make sure the chargepoint model is correct and matches the order.
NOTE: Items damaged in transit must first be reported to the courier and then to the
supplier. Where possible, photographic evidence of package and/or item damage
should be provided.
NOTE: Incorrect or damaged units must NOT be installed. Contact your supplier to
discuss rectification.
5. If required, prepare the site by installing a ground mounting base or by assessing
the ground/surface condition so that the chargepoint can be mounted directly to
the surface.
x If protective bollards or barriers will be used, consider installing them at the
point of site preparation.
x Cables requiring entry into the chargepoint enclosure should be positioned so
they will enter from under the bottom of the pedestal.
6. Familiarise yourself with the schematic that is relevant to the product to be installed.
NOTE: 4-Way chargers are, essentially, 2x 2-way chargers in one pedestal.
If a Ground Mounting Base Will be Used:
1. Prepare the ground and set the ground mounting base in the desired location.
x Make sure the power supply cable, the ethernet cable (if required), and the
Load Balancing CT cable (if required) are fed upward through the middle of
the base.
2. Concrete the base into place and allow time for it to set.
x The lip of the base should be 2 – 3 mm above the surrounding ground level.
If a Ground Mounting Base Will Not be Used:
1. Prepare a suitable area of firm, flat ground.
2. Use the rubber mat as template to mark where the mounting holes are to be made
in the ground.
x It must be possible to secure the chargepoint to the ground with bolts or similar
fixings that are appropriate to the type of prepared ground.
x Typically, into concrete, M8 x 100 mm Anchor Bolts should be used but installers
must assess the site and choose the most appropriate fixing for their needs.
x Make sure the power supply cable, the ethernet cable (if required), and the
Load Balancing CT cable (if required) are fed upward through the middle of
the pedestal mounting location.
3. Securing points in the prepared ground must align with pre-made holes in the base
of the pedestal. If required, the securing points can be installed using the
chargepoint as a template during the installation steps.
IMPORTANT: Only use the chargepoint as a template to mark the location of the
securing points. Do NOT drill through the pedestal into the prepared surface. Dust
and/or other contamination can damage components and will invalidate the
warranty.
