Reference Manual
00809-0100-4021, Rev FB
August 2011
Rosemount 3144P
4-34
FOUNDATION Fieldbus
All other custom tags that are entered must be: numbers 0 - 9, letters A - Z,
and/or spaces.
The following are the standard temperature units codes displayed on the
LCD:
All other custom units that are entered must be: numbers 0 - 9, letters A - Z,
and/or spaces.
If the value of the process variable displayed has a bad or uncertain status,
the following is shown:
When power is first applied, the LCD will display the following:
If the device goes from “Auto” mode to Out-of-Service (OOS) mode, the LCD
will display the following:
CHAR 2000 “CHAR”
ARITH 2100 “ARITH”
OSPL 2200 “OSPL”
Units LCD bottom line
Degrees C “DEG C”
Degrees F “DEG F”
Degrees K “DEG K”
Degrees R “DEG R”
Ohms “OHMS”
Millivolts “MV”
Percent (%) Uses the percent symbol
Status LCD bottom line
Bad “BAD”
Uncertain “UNCTN”
LCD top line LCD bottom line
“3144” blank
LCD top line LCD bottom line
“OOS” blank
Block Name LCD bottom line
