Reference Manual
00809-0100-4021, Rev FB
August 2011
Rosemount 3144P
A-16
SPARE PARTS LIST
Quality Certification for Safety
Standard Standard
QS Prior-use certificate of FMEDA data (HART Only) ★
QT Safety-certified to IEC 61508 with certificate of FMEDA data (HART only) ★
Shipboard Certification
Standard Standard
SBS American Bureau of Shipping (ABS) Type Approval ★
SBV Bureau Veritas (BV) Type Approval ★
SDN Det Norske Veritas (DNV) Type Approval ★
SLL Lloyd's Register (LR) Type Approval ★
Conduit Electrical Connector
Standard Standard
GE
(6)
M12, 4-pin, Male Connector (eurofast
®
) ★
GM
(6)
A size Mini, 4-pin, Male Connector (minifast
®
) ★
Assemble To Options
Standard Standard
XA Sensor Specified Separately and Assembled to Transmitter ★
Typical Model Number: 3144P D1 A 1 E5 B4 M5
(1) When IS approval is ordered on a FOUNDATION fieldbus, both standard IS and FISCO IS approvals apply. The device label is marked appropriately.
(2) Consult factory for availability when ordering with HART or F
OUNDATION fieldbus models.
(3) Consult factory for availability when ordering with F
OUNDATION fieldbus models.
(4) Codes U1 and U6 for HART transmitters will not have drift alert enabled; option codes U1, U6, U7, U8, and U9 for F
OUNDATION fieldbus transmitters will
have drift alert enabled.
(5) Not available for F
OUNDATION Fieldbus.
(6) Available with Intrinsically Safe approvals only. For FM Intrinsically Safe or non-incendive approval (option code I5), install in accordance with Rosemount
drawing 03151-1009 to maintain 4X rating.
Table A-3. Rosemount 3144P Temperature Transmitter Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.
Parts Description
Part Number
Electronic Module
Rosemount 3144P Hart Electronics Spare Kit (Configured as Single Sensor) 03144-3111-0001
Rosemount 3144P Hart Electronics Spare Kit (Configured as Dual Sensor) 03144-3111-0002
Rosemount 3144P SIS Electronics Spare Kit (Configured as Single Sensor) 03144-1610-0001
Rosemount 3144P SIS Electronics Spare Kit (Configured as Dual Sensor) 03144-1610-0002
Rosemount 3144P Fieldbus Electronic Spare Kits (Configured as Single Sensor) 03144-5601-0001
M5 Meter Kit (Includes meter display, captive mounting hardware, 10-pin interconnection header and cover)
M5 Meter Kit - Aluminum 03144-3120-0001
M5 Meter Kit - Stainless Steel 03144-3120-0011
Meter
(includes meter, captive mounting hardware, and 10-pin interconnection header)
03144-3120-0002
Meter Cover Kit
Aluminum Meter Cover Kit (includes cover and O-ring) 03144-1043-0001
Mounting Bracket Kit
B4 Mounting Bracket Kit SST 03044-2131-0001
B5 Mounting Bracket Kit SST 03144-1081-0001
B5 Mounting Bracket Kit 316 SST 03144-1081-1001
Housing Cover (Includes O-ring and wiring diagram label)
Rosemount 3144P Aluminum Housing Cover 03144-1142-0001
Rosemount 3144P Stainless Steel Housing Cover 03144-1142-0002
O-ring for cover (pkg of 12) 01151-0033-0003
