Rosemount 3144P
Standard Configuration
Both standard and custom configuration settings may be changed. Unless specified, the transmitter will be shipped
as follows:
Housing Kit (does not include covers)
Rosemount 3144P Aluminum Housing Kit 03144-1141-0001
Rosemount 3144P Aluminum Housing Kit with External Ground Lug Assembly 03144-1141-0002
Rosemount 3144P Stainless Steel Housing Kit 03144-1141-0003
Rosemount 3144P Stainless Steel Housing Kit with External Ground Lug Assembly 03144-1141-0004
Rosemount 3144P Cover Clamp Kit 03144-1048-0001
Others
Screw/Washer combination for Sensor/ Power Terminals (pkg of 12) 03144-1044-0001
Jumper (10 pin) - Meter interconnection header (pkg of 12) 03144-1146-0001
External Ground Lug Assembly (includes all hardware to be used with existing ground lug installed in transmitter -
including knurled insert)
03144-1047-0001
Integral Transient Protector Kit - HART Only (includes terminal screws, transient protector and external ground lug
assembly)
03144-3045-0001
Integral Transient Protector Kit - Fieldbus Only (includes terminal screws, transient protector and external ground
lug assembly)
03144-3045-0002
Standard Configuration
4 mA value / Lower Range (HART / 4–20 mA) 0 °C
20 mA value / Upper Range (HART / 4–20 mA) 100 °C
Damping 5 seconds
Output Linear with temperature / FOUNDATION fieldbus
Failure Mode (HART / 4–20 mA) High
Line Voltage Filter 60 Hz
Software Tag See “Tagging”
Optional Integral Meter Units and mA / Sensor 1 units
Single Sensor option
Sensor Type 4-wire Pt 100 = 0.00385 RTD
Primary Variable (HART / 4–20 mA) Sensor 1
Secondary Variable Terminal (Body) Temperature
Tertiary Variable Not Available
Quaternary Variable Not Available
Dual-Sensor option
Sensor Type Two 3-wire Pt 100 = 0.00385 RTD
Primary Variable (HART / 4–20 mA) Sensor 1
Secondary Variable Sensor 2
Tertiary Variable Terminal Temperature
Quaternary Variable Not Used
