Reference Manual
00809-0100-4021, Rev FB
August 2011
Rosemount 3144P
3-10
HART
Device Dashboard Fast
Key Sequences
Fast key sequences are listed below for common 3144P transmitter functions.
NOTE:
The fast key sequences assume that “Device Revision Dev v4, DD v3” is
being used. Table 3-2 provides alphabetical function lists for all Field
Communicator tasks as well as their corresponding fast key sequences.
Table 3-2. Fast Key Sequences
Function HART Fast Keys
Alarm Values 2, 2, 5, 6
Analog Output 2, 2, 5
Average Temperature Setup 2, 2, 3, 2
Burst Mode 2, 2, 8, 3
Burst Option 2, 2, 8, 4
Configure Hot Backup 2, 2, 4, 1, 3
Date 2, 2, 7, 1, 2
Descriptor 2, 2, 7, 1, 3
Device Information 2, 2, 7, 1
Differential Temperature Setup 2, 2, 3, 1
Drift Alert 2, 2, 4, 2
Filter 50/60 Hz 2, 2, 7, 5, 1
First Good Temperature Setup 2, 2, 3, 3
Hardware Revision 1, 8, 9, 3
Intermittent Sensor Detect 2, 2, 4, 2, 1
Intermittent Threshold 2, 2, 4, 2, 2
Loop Test 3, 5, 1
LRV (Lower Range Value) 2, 2, 5, 5, 3
Message 2, 2, 7, 1, 4
Open Sensor Holdoff 2, 2, 7, 4
Percent Range 2, 2, 5, 4
Sensor 1 Configuration 2, 2, 1
Sensor 2 Configuration 2, 2, 2
Sensor 1 Serial Number 2, 2, 1, 7
Sensor 2 Serial Number 2, 2, 2, 7
Sensor 1 Setup 2, 2, 1
Sensor 2 Setup 2, 2, 2
Sensor 1 Type 2, 2, 1, 2
Sensor 2 Type 2, 2, 2, 2
Sensor 1 Unit 2, 2, 1, 4
Sensor 2 Unit 2, 2, 2, 4
Software Revision 1, 8, 9, 4
Tag 2, 2, 7, 1, 1
Terminal Temperature Units 2, 2, 7, 3
URV (Upper Range Value) 2, 2, 5, 5, 2
Variable Mapping 2, 2, 8, 5
2-wire Offset Sensor 1 2, 2, 1, 5
2-wire Offset Sensor 2 2, 2, 2, 5
