Rosemount 3144P
PlantWeb Advanced Diagnostic Functionality
Standard Standard
D01 Diagnostics Suite: Statistical Process Monitoring (SPM), Thermocouple Diagnostic, Min/Max Tracking –
F
OUNDATION fieldbus only
★
Mounting Bracket
Standard Standard
B4 Universal Mounting Bracket for 2-inch pipe and panel mounting—SST bracket and bolts ★
B5 Universal “L” Mounting Bracket for 2-inch pipe mounting—SST bracket and bolts ★
Display
Standard Standard
M5 LCD Display ★
External Ground
Standard Standard
G1 External Ground Lug Assembly (See “External Ground Screw Assembly” on page A-3.) ★
Transient Protector
Standard Standard
T1 Integral Transient Protector ★
Software Configuration
Standard Standard
C1
(3)
Custom Configuration of Date, Descriptor and Message (Requires CDS with order) ★
Line Filter
Standard Standard
F5 50 Hz Line Voltage Filter ★
Alarm Level Configuration
Standard Standard
A1 NAMUR alarm and saturation levels, high alarm ★
CN NAMUR alarm and saturation levels, low alarm ★
Low Alarm
Standard Standard
C8 Low Alarm (Standard Rosemount Alarm and Saturation Values) ★
Sensor Trim
Standard Standard
C2 Transmitter-Sensor Matching – Trim to Specific Rosemount RTD Calibration Schedule (CVD constants) ★
Expanded
C7 Trim to Non-Standard Sensor (Special Sensor–Customer must provide sensor information)
5-Point Calibration
Standard Standard
C4 5-Point Calibration (Requires the Q4 option code to generate a Calibration Certificate) ★
Calibration Certification
Standard Standard
Q4 Calibration Certificate (3-Point Calibration) ★
QP Calibration Certificate and Tamper Evident Seal ★
Dual-Input Custom Configuration (only with measurement type option code 2)
Standard Standard
U1
(4)
Hot Backup ★
U2
(5)
Average temperature with Hot Backup and Sensor Drift Alert – warning mode ★
U3
(5)
Average temperature with Hot Backup and Sensor Drift Alert – alarm mode ★
U5 Differential temperature ★
U6
(4)
Average temperature ★
U7
(4)
First good temperature ★
Expanded
U4 Two independent sensors
Table A-3. Rosemount 3144P Temperature Transmitter Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.
