Reference Manual
00809-0100-4021, Rev FB
August 2011
Rosemount 3144P
A-10
Transducer Block
• Contains the actual temperature measurement data, including Sensor 1,
Sensor 2, and terminal (body) temperature
• Includes information about sensor type and configuration, engineering
units, linearization, range, damping, and diagnostics
LCD Block (when an LCD display is used)
• Configures the local display
Analog Input (AI)
• Processes the measurement and makes it available on the fieldbus
segment
• Allows filtering, engineering unit, and alarm changes
PID Block (provides control functionality)
• Performs single loop, cascade, or feedforward control in the field
Block Execution Time
Resource –
Transducer –
LCD Block –
Advanced Diagnostics –
Analog Input 1, 2, 3 60 milliseconds
PID 1 and 2 with Autotune 90 milliseconds
Input Selector 65 milliseconds
Signal Characterizer 45 milliseconds
Arithmetic 60 milliseconds
Output Splitter 60 milliseconds
