Reference Manual
00809-0100-4021, Rev FB
August 2011
B-11
Rosemount 3144P
Special Conditions for Safe Use (X):
1.The apparatus enclosure may contain light metals. The apparatus must
be installed in such a manner as to minimize the risk of impact or friction
with other metal surfaces.
2. A transient protection device can be fitted as an option, in which the
equipment will not pass the 500 V test.
International Certifications
IECEx Certification
E7 IECEx Flameproof Approval (Zone 1)
Certificate Number: IECEx KEM 09.0035X
Ex d IIC T6 (T
amb
= -40 to 70 °C)
Ex d IIC T5 (T
amb
= -40 to 80 °C)
Maximum Supply Voltage: 55 Vdc
Special Condition for Safe Use (X):
For information on the dimensions of the flameproof joints the
manufacturer shall be contacted.
NK IECEx Dust Ignition Proof Approval
Certificate Number: IECEx KEM 09.0036
Ex tD A20 IP66 T95 °C (T
amb
= -40 to 80 °C)
Maximum Supply Voltage: 55 Vdc
Consult factory for NF availability.
N7 Type n Approval (Zone 2)
Certificate Number: IECEx BAS 07.0005X
Ex ia IIC T4 (T
amb
= –40 to 75 °C)
Maximum Supply Voltage: 42.4 V
Enclosure: IP66
I7 Intrinsic Safety Approval
Certificate Number: IECEx BAS 07.0004X
Ex ia IIC T4 (T
amb
= –60 to 60 °C)
Special Conditions for Safe Use (x):
When fitted with the transient terminal options, the apparatus is not
capable of withstanding the 500 V electrical strength test as defined in
Clause 6.8.1 of IEC 60079-15: 2005. This must be taken into account
during installation.
Power/Loop FISCO Power/Loop Sensor
U
i
= 30 Vdc U
i
= 17.5 Vdc U
o
= 13.9 Vdc
I
i
= 300 mA I
i
= 380 mA I
o
= 23 mA
P
i
= 1.3 W P
i
= 5.32 W P
o
=79 mW
C
i
= 2.1 nF C
i
= 2.1 nF C
i
= 7.7 nF
L
i
= 0 L
i
= 0 L
i
= 0
