Table 2-1 – Recommended bolts for
bracket-to-customer interface
(1) The Bracket Code can be found in the 13
th
position of the 3152, 3153 and 3154 model strings
(2) Bracket Codes 1 and 5 are available on the 3152 and 3153-series only
(3) Bracket Codes 2 and 7 are available on the 3152, 3153 and 3154-series
(4) Bracket Codes 3 and 8 are available on the 3152, 3153 and 3154-series; this bracket code includes the listed bracket along
with the pipe mount hardware (Rosemount P/N 01154-0044-0001)
BRACKET
CODE
(1)
BRACKET TYPE
RECOMMENDED BOLT
FOR BRACKET TO
CUSTOMER INTERFACE
0
No Bracket
Supplied
N/A
1
(2)
Carbon Steel
Panel Bracket
5/16-18 UNC 2A Grade 2
2
(3)
SST Panel
Bracket
3/8-24 UNF 2A Grade 2
3
(4)
SST 2” Pipe
Mount Bracket
3/8-24 UNF 2A Grade 2
5
(2)
Carbon Steel
Panel Bracket
5/16-18 UNC 2A Grade 2
7
(3)
SST Panel
Bracket
3/8-24 UNF 2A Grade 2
8
(4)
SST 2” Pipe
Mount Bracket
3/8-24 UNF 2A Grade 2
