Rosenbauer FOX 4 - Screen

Technical description
36 / 127
LCS operation panel
6.4.2 Screen
Pump
Priming pump
The switch activates and deactivates the
priming pump.
Governor
The speed is regulated with the governor
and this adjusts the water pump pres-
sure.
Idling speed
The switch adjusts the engine speed to
idling and reduces the pump pressure ac-
cordingly.
Lighting
The switch activates and deactivates the
lighting of the portable pump.
The switch has four switching positions:
• Working lights and fuel tank cap
lighting active
• Carrying frame lighting active
• All lighting active
• All lighting inactive
Symbol Name Functional description
Symbol Name Functional description
Propulsion engine
speed
The indicator shows the current speed of
the propulsion engine.
Water pump intake
pressure
The indicator shows the current intake
pressure at the water pump.
Pump pressure of
the water pump
The indicator shows the current pump
pressure of the water pump.
