Technical description
40 / 127
Optional equipment
6.5 Optional equipment
6.5.1 Tool kit
The tool kit is equipped with the most important tools for the portable pump.
Scope of delivery
•Tool bag
• TORX TX20 angle screwdriver
• TORX TX30 angle screwdriver
• Spark plugs applicator 5/8 square 16 mm
• 3 pcs. spark plugs
• Oil drain hose M22 x 1.5
6.5.2 Exhaust gas hose
DANGER!
Inhalation of toxic exhaust fumes can cause death or serious health
damage!
Toxic gases are produced when running a combustion engine. Operation in
the immediate vicinity of flammable material and substances is prohibited.
In order to properly discharge hot exhaust gases, use the provided,
standardised exhaust hose. An incorrect exhaust gas hose can lead to heat
build-up in the unit and thus endanger the operating personnel and the unit.
Place the hose outlet outside the working area. Let the exhaust gas hose
cool down before dismantling.
Use a maximum of one exhaust gas hose according to DIN 14572.
Diameter minimum 50 mm (2 in). Length maximum 1.5 m (59 in).
If no exhaust gas hose is used, then position the unit so that the exhaust
gases can be freely discharged from the device.
If operation of internal combustion engines in enclosed spaces is absolutely
necessary, note the following:
Extract the exhaust gases by means of the exhaust gas hose.
Ensure there is adequate ventilation.
The exhaust gas hose, according to DIN 14572, is equipped with 2 wooden
handles for operation.
Technical data:
• Length: 1500 mm (59 in)
• Diameter: 50 mm (2 in)
