Operation
48 / 127
Transport
Mount wheel set
Transporting portable pump
► Swivel out the carrying handles of the portable pump.
► Push down the carrying handles and turn into the direction of trav-
el.
► Lift portable pump on the carrying handles.
► Lift the portable pump so far that the portable is on the wheels.
Portable pump can be moved by 1 person.
► Swivel the carrying handles of the portable pump back in after trans-
porting.
► Push the carrying handles down and swivel in.
Additional operating personnel are required to move on inclined passages
and slopes.
Disassemble wheel set
► The disassembly of the wheel set takes place in reverse order to the
assembly.
The wheels are disassembled.
► The axle bearing can remain mounted on the portable pump.
The wheel set is disassembled.
The portable pump can be transported with the carrying handles.
