Service and cleaning
92 / 127
Testing and inspection work
1 Engine oil dipstick
2 Air filter
3 Coolant expansion tank of the propulsion engine
4 Priming pump oil dipstick
Oil dipstick with marking
The correct engine oil level is determined in two stages.
► Check engine oil level in cool condition.
It is checked whether there is enough engine oil for a test at oper-
ating temperature.
► Check engine oil level at operating temperature of the engine.
The precise engine oil level is checked.
Check engine oil level in cool condition
The work steps corresponds to the sticker on the portable pump.
The sticker is located next to the engine oil dipstick.
Sticker on the portable pump
► Position the portable pump on a flat, even surface.
► Start propulsion engine.
1.
2.
30 sek.
3.
4.
}
05722B-999
START
