Service and cleaning
94 / 127
Testing and inspection work
► Remove the engine oil dipstick again.
► Check engine oil level.
The engine oil level must be just below the top marking.
► If the engine oil level is too low, add oil
Refer to chapter "Lubrication table".
The oil quantity between the top and bottom markings is approx
500 ml (0.13 gal).
The engine oil level has been checked.
Coolant of the propulsion engine
CAUTION!
Burning hazard from the hot cooling system!
Only carry out maintenance work after the portable fire pump has been
shut down and the cooling system has cooled down.
NOTICE
Engine damage due to poor cooling!
Prohibited liquids lead to poor cooling and cause engine damage.
Do not use water to top up.
Only use recommended and approved coolant.
1 Engine oil dipstick
2 Air filter
3 Coolant expansion tank of the propulsion engine
4 Priming pump oil dipstick
