Rosslare AC-A41 User Manual

Technical Specifications
10 AC-A4x Installation and Programming Manual
2. Technical Specifications
Electrical Characteristics
Operating Voltage Range
12–16 VDC
From a regulated power supply
Input Current
Standby: 40 mA (excluding attached
devices)
Max: 100 mA (excluding attached
devices)
Relay Outputs
 Lock Strike Relay – 3.5 A with built-
in suppressor protection

Auxiliary Relay – Form C, 1 A
Inputs
 REX: N.O., Dry Contact
 Auxiliary Input (In/Monitor):
 Monitor mode: N.C., Dry
Contact
 Input Mode: N.O., Dry Contact
LEDs
Two tri-colored LEDs
Built-In Proximity Reader (AC-
A42)
 Read Range:* 3.5 in. (90 mm)
 Modulation: ASK at 125 kHz
 Compatible cards: All 26-Bit EM
cards
Environmental Characteristics
Operating Temperature
-25°F to 145°F (-32°C to 63°C)
Operating Humidity
0 to 95% (non-condensing)
Mechanical Characteristics
Dimensions
Length x Width x Depth
4.80 in. x 2.95 in. x 0.94 in.
(122 x 75 x 24 mm)
Weight
0.3 lb (140 g)
* Measured using Rosslare Proximity Card (AT-11/12) or equivalent.
Range also depends on electrical environment and proximity to
metal

Rosslare AC-A41 Specifications

General

Brand	Rosslare
Model	AC-A41
Category	Controller
Language	English
