Programming the AC-A4x
28 AC-A4x Installation and Programming Manual
3.
There are four different ways to program the Normal/Bypass code
and door chime:
 Disable both Bypass code
and the door
chime. Enter the code 0000.
 Disable Bypass code and enable the
door chime. Enter the code 0001.
 Enable Bypass code and disable the
door chime. Enter any code ending
with 0.
 Enable Bypass code and enable the
door chime. Enter a code not ending
with 0.
The system returns to Normal mode:
 Three beeps are emitted.
 The Door LED turns off.
 The Mode LED turns green.
The door is only generated when the Lock Strike Relay is
activated due to a valid code entry.
11.8 Defining the Auxiliary Input and Output
1. Enter Programming mode.
2. Press 6 to enter Menu 6.
The Mode LED flashes green.
Mode
Door
Green
Mode
Door
Green
Mode
Door
Green
Green
