Introduction
8 AC-A4x Installation and Programming Manual
1. Introduction
The AC-A4x access control units are indoor standalone controllers.
The units accept up to 500 users and allow entry via a personal
identification number (PIN) and/or by presenting a proximity card
1.1 Reader/Controller Types
The two types of units described in this manual are:
Keypad Type PIN Proximity
AC-A41
Standard  
AC-A42
Standard  
1.2 Key Features
 Built in keypad for PIN code entry
 Built-in proximity card reader (125 KHz ASK modulation) (AC-A42
only)
 Auxiliary Input and Auxiliary Output
 Eight Auxiliary Modes including Door Ajar, Forced Door, Shunt,
Door Monitor, and Normal/Secure
 Internal buzzer
 Comes with security screw and security screw tool
 Two status/programming interface LEDs
 Three user levels (Normal User, Secure User, Master User)
 Three modes of operation (Normal Mode, Bypass Mode, Secure
Mode)
 "Code Search" feature simplifies maintaining user codes
 Input for REX button
 Lock Strike Electronic Relay with built-in suppressor protection
 Comes with mounting template for easier installation
 Built-in case and back tamper
