Programming the AC-A4x
38 AC-A4x Installation and Programming Manual
11.12.1 Lock Strike Relay and Auxiliary Relay Code
Assignment using Standard Method
1. Enter Programming mode.
The Mode LED turns green and the Door
LED turns orange.
3. Enter the 3-digit user slot for code
assignment.
The Mode LED flashes green.
4. Enter the assignment digit for the current user slot:
1 activates the Lock Strike relay only default
2 activates the Auxiliary relay only
3 activates the Lock Strike and Auxiliary relays
If the assignment code is valid, the Mode indicator stops flashing.
The controller is now waiting for another slot number.
5. Press # to move to the next slot or enter a new slot number.
If you do not wish to continue, press # twice and the controller
returns to Normal mode.
11.12.2 Lock Strike Relay and Auxiliary Relay Code
Assignment using Search Method
1. Enter Programming mode.
