Rosslare AC-A41 User Manual

Programming the AC-A4x
30 AC-A4x Installation and Programming Manual
Table 2: Quick Reference Guide for Auxiliary Mode Setting
Aux. Mode Aux. Input
Function
Aux. Output
Activated by
Aux. Relay Aux. Settings
(in seconds)
0 REX-2 Valid code or REX-2 N.O. 01 to 99 Aux. Relay
Release Time
00 Aux. Relay Toggles
1 Normal/Secure switch Valid code N.O. 01 to 99 Aux. Relay
Release Time
00 Aux. Relay Toggles
2 Normal/Secure switch Bell button N.O. 01 to 99 Aux. Relay
Release Time
00 Aux. Relay Toggles
3 Normal/Secure switch Tamper event N.C. 01 to 99 Aux. Relay
Release Time
00 Aux. Relay
activated by Tamper
4 Normal/Secure switch Direct shunt N.O.
00 to 99 Shunt time
5 Door Monitor Shunt N.C. 00 to 99 Maximum
shunt time
6 Door Monitor Forced door N.C. 00 to 99 Forced delay
7 Door Monitor Door ajar N.C.
00 to 99 Ajar delay
