Wiring Instructions
AYC-E/Q/T60 Family Installation and Programming Manual 17
4. Wiring Instructions
The unit is supplied with 56-cm (22”) pigtail, having a 6-conductor
cable.
To connect the unit to the controller:
1. Prepare the unit's cable by cutting the cable jacket back 3.2 cm
(1¼”) and stripping the wire 1.3 cm (½”).
2. Splice the unit’s pigtail wires to the corresponding controller wires
and cover each connection.
Refer to Table 1 and to the wiring diagrams provided on the following
pages.
Table 1: Wiring Colors
Reader Controller Color Functionality
5~16 VDC 5~16 VDC Red +DC Input
Shield/Ground Shield/Ground Black Ground
Data 1/Clock C 1 White Communication
Data 0/Data C 2 Green Communication
G.LED/LEDCTL AUX. IN Brown LED Control/Auxiliary Input
Tamper Tamper Purple Tamper
3. If the tamper output is used, connect the purple wire to the
correct input on the controller when used as a reader, or to a
zone input of an intruder alarm system when used as a controller.
4. Trim and cover all unused conductors.
• The individual wires from the unit are color-coded according the
Wiegand standard.
• When using a separate Power Supply for the Reader, this Power
Supply and that of the Controller must have a common ground.
• The Reader’s cable shield wire should preferably be attached to an
