Controller Functionality
64 AYC-E/Q/T60 Family Installation and Programming Manual
6.10.16.1 Relay Code Assignment using the Standard Method
To assign relay code using the Standard method:
1. Enter Programming mode.
2. Press 9 to enter Menu 9.
The Mode LED turns green and
the Door LED turns orange.
3. Enter the 3-digit user slot for
code assignment.
The Mode LED flashes green.
4. Enter the assignment digit for the current user slot:
1 activates the Lock Strike relay only default
2 activates the Auxiliary relay only
3 activates the Lock Strike and Auxiliary relays
If the assignment code is valid, the Mode LED stops flashing.
The controller is now waiting for another slot number.
5. Press # to move to the next slot or enter a new slot number.
6. If you do not wish to continue, press # twice and the controller
returns to Normal mode.
6.10.16.2 Relay Code Assignment using the Search Method
To assign relay code using the Search method:
1. Enter Programming mode.
2. Press 9 to enter Menu 9.
