INSTALLATION MANUAL
BRP-Powertrain
Effectivity: 912 i Series
Edition 1/Rev. 2
73-00-00
Page 9
January 01/2014
NOTE: The cable length for the fuel pumps can be extended, if
necessary. For this a ROTAX plug kit is available.
1.8.1) Current input (Operating condition of the fuel pumps: ON)
Do not connect additional load (additional fuel pumps,
lamps, LED, etc.) to the power supply of the fuel
pumps.
The wiring is manufactured for the GENUINE ROTAX
fuel pump assy. only.
Voltage Current
12 V 9.1 A
14 V 10.1 A
16 V 11.2 A
