1.8.2) Technical data
Graphic The technical data of the fuel pumps provided by ROTAX is shown below.
See Fig. 2 and Fig. 3.
a) Dimensions:Connection 9/16-18 UNF
Fig. 2 06333
Part Function
1 Fuel pump assy.
157mm
73mm
247.3mm (9.74in.)
1
213.5mm (8.41in.)
14.5mm
9/16-18 UNF
(6.18 in.)
(2.87 in.)
(0.57 in.)
