INSTALLATION MANUAL
BRP-Powertrain
Effectivity: 912 i Series
Edition 1/Rev. 0
79-00-00
Page 14
January 01/2012
UNF thread
Optional
Oil feed line and outlet have UNF threads
Purging nipple
Bent socket 90°
Optional
part no. 956580
Nipple optional part no. 956610
Screw connection
Thread 3/4-16 UNF
Tightening torque of oil feed line and out-
let
25 Nm
(18.44 ft.lb.)
The oil tank cover is also marked with the designa-
tions
IN- oil return line from crankcase
OUT- outlet to oil cooler/oil pump.
Purging nipple
Outer dia. 8 mm (0.31 in.)
Slip-on length max. 15 mm
(0.59 in.)
Bent socket 90° / M18x1.5
Outer dia. 12 mm
(0.47 in.)
Slip-on length max. 24 mm
(0.94 in.)
Tightening torque 25 Nm
(18.44 ft.lb.)
Nipple with cap nut / straight
Outer dia. 12 mm
(0.47 in.)
Slip-on length max. 24 mm
(0.94 in.)
Tightening torque 25 Nm
(18.44 ft.lb.)
