Rotax 912 i series Installation Manual

d05781.fm
INSTALLATION MANUAL
BRP-Powertrain
Effectivity: 912 i Series
Edition 1/Rev. 2
24-00-00
Page 25
January 01/2014
Optional
External alternator indicator lamp
* optionally a key switch can be used.
EXTERNAL ALTERNATOR IN-
DICATOR LAMP
Requirement Connector/slot
Lamp colour In accordance with the regulati-
ons
Nominal voltage 12 V
Nominal current Maximum 300 mA
Designation on wiring harness Not connected to the wiring har-
ness.

WARNUNG
NOTICE
If using LED they will always glow, even with no alarm
or warning shown!
Remedy: The use of 2 resistores as shown on page
34.
START SWITCH* Requirement Connector/slot
Switch type Push button HIC B
Nominal voltage 28 VDC
Nominal current 5 A
Number of poles 1-pole
Designation on wiring harness CONN_STARTER_REL_SW 4
SUPP_START_SWITCH 12

Rotax 912 i series Specifications

General

Number of Cylinders	4
Max Power	100 hp (73.5 kW)
Max Power Output RPM	5800 rpm
Ignition System	Dual electronic ignition
Oil System	Dry sump, forced lubrication with separate oil tank
Reduction Gear Ratio	2.43:1
TBO	2000 hours
Engine Type	4-stroke, horizontally opposed
Displacement	1352 cm³
Bore x Stroke	84 mm x 61 mm
Max Torque	128 Nm
Fuel Type	Avgas 100LL or unleaded automotive gasoline
Fuel System	Electronic fuel injection
Cooling System	Liquid/air-cooled
