INSTALLATION MANUAL
BRP-Powertrain
Effectivity: 912 i Series
Edition 1/Rev. 2
24-00-00
Page 28
January 01/2014
Start Power Relay (Option 2)
Key Switch (Option 2)
START POWER RELAY
(optional)
Requirement Connector/slot
Switch type Relay
Nominal voltage 28 VDC
Nominal current 20 A
Min. control voltage Tbd from aircraft manufacturer
Number of poles 2 Polic NO (normally open)
Designation on wiring harness Not connected to the wiring har-
ness.
KEY SWITCH (optional) Requirement Connector/slot
Switch type Off/ON
Nominal voltage 28 VDC
Nominal current 5 A
Number of poles 2-pin
Designation on wiring harness Not connected to the wiring har-
ness.
