Roto NT Power Hinge - Page 39

Subject to change. Roto NT IMO_347_EN_v0
.
July 2014
.
39
Hardware overview
NT hinge side K (PVC) – Turn-Only / Tilt&Turn hardware
RC1/RC1N (DINEN1627–1630)
4 mm clearance
5
Corner drive 1 V 260272
5a
Corner drive, T&T 1 V 260288
8
Multipart centre lock, bottom horizontal
SRW / mm Size Material no.
600 – 800 400 1 V 296854
801 – 1000 600 1 V 296855
1001 – 1200 600 CON 1 V 337711
200 1 V 296853
1201 – 1400 600 CON 1 V 337711
400 1 V 296854
16
Run-up block 350402
10 mm clearance
5
Corner drive 1 V 566650
5a
Corner drive, T&T 1 V 614456
8
Multipart centre lock, bottom horizontal
SRW / mm Size Material no.
600 – 800 400 1 V 566651
801 – 1000 600 1 V 618553
1001 – 1200 600 CON 1 V 618553
200
1 V
618552
1201 – 1400 600 CON 1 V 618553
400 1 V 566651
16
Run-up block 601500
14
Corner hinge K 3/100 230343
Corner hinge K 6/130 not dep. 263858
15
Pivot rest K 3/100 258590
Pivot rest K 6/100 not dep. 258592
Pivot rest K3/100 not dep.
(for low tilting axis) 306662
Profile-related components
6
Tilt striker threshold set Eifel 13mm
2-sashed centre
730427
7
Tilt striker threshold set Eifel 13mm 534929
Tilt striker threshold set Eifel 9 mm 496779
1) For RC2 SRH 1800–2400mm
Application range
Sash rebate width SRW act. sash (T&T) .........600 – 1400 mm
Sash rebate width SRW pass. sash (TU-ON)
.600 – 1400 mm
Sash rebate height SRH ................................ 1600 – 2600mm
1)
Sash weight S.kg ...................................................max. 100 kg
NOTE!
This document excerpt does not replace the
complete product documentation*. Non-com-
pliance exempts the hardware manufacturer of
his liability.
For all other Tilt&Turn hardware components
refer to:
 CTL_7_EN
* Can be found on www.roto-frank.com
