Subject to change. Roto NT IMO_347_EN_v0

July 2014

Product characteristics

Vapour diffusion-proof

Juist construction connection sheeting

Description Width Surface-finish

PQ Material no.

Construction

connection sheeting

200 mm Black 60 m 543437

Parts list – Roto Eifel TB

Accessories

Juist construction connection sheeting
