Roto NT Power Hinge - Accessories; Additional Profiles

62
.
July 2014
.
IMO_347_EN_v0 Roto NT Subject to change.
20
20
35
35
25
31
* Thermal separation must be processed.
Note: The use of additional profi les changes the U
f,BW
value and the isothermal curve.
KS-20 base profile
Description Length Surface-fi nish PQ Material no.
KS-20 base profi le 6 m White 60 m 543809
KS-20 base profi le 6 m Black 60 m 543936
KS-20 base profi le 6 m Grey 60 m 543939
KS-20 base profi le 1.18 m White 5pcs 543810
KS-20 base profi le 1.18 m Black 5pcs 543937
KS-20 base profi le 1.18 m Grey 5pcs 543940
KS-35 base profile
Description Length Surface-fi nish PQ Material no.
KS-35 base profi le 6 m White 60 m 550007
KS-35 base profi le 6 m Black 60 m 544274
KS-35 base profi le 6 m Grey 60 m 544277
KS-35 base profi le 1.18 m White 5pcs 550008
KS-35 base profi le 1.18 m Black 5pcs 544275
KS-35 base profi le 1.18 m Grey 5pcs 544278
End cap for KS-35 base profile (can be shortened)
Description Surface-fi nish PQ Material no.
End cap for KS-35 base profi le White 50pcs 544516
Outward-opening additional profile*
Description Length Surface-fi nish PQ Material no.
Outward-opening
additional profi le
6 m E6 / C-0 60 m 551380
Outward-opening
additional profi le
1.18 m E6 / C-0
25pcs 550061
Hardware mounting profile* 25mm
Description Length Surface-fi nish PQ Material no.
HM profi le 25 mm 6 m E6 / C-0 60 m 544108
HM profi le 25 mm 1.18 m E6 / C-0
25pcs 544109
Hardware mounting profile* 31 mm
Description Length Surface-fi nish PQ Material no.
HM profi le 31 mm 6 m E6 / C-0 60 m 545744
HM profi le 31 mm 1.18 m E6 / C-0
25pcs 545745
Parts list – Roto Eifel TB
Accessories
Additional profiles
