88
.
July 2014
.
IMO_347_EN_v0 Roto NT Subject to change.
Operation
Operating information
Handle positions of Tilt&Turn hardware
The following symbols show the different handle positions and the resulting
sash positions of windows and balcony doors.
Handle position Sash position Symbol Meaning
Closed position of the sash
Opened turn position of the sash
Opened tilt position of the sash
Malpositioning of the sash
