Adjustment
Explanation on the adjustment chapter
Symbols for the sash adjustment when installed
These symbols facilitate the orientation while adjusting the window sashes
after installation with the following steps. Use a 4mm Allen key as tool.
Height adjustment
Lateral adjustment
Gasket-compression adjustment
NOTE!
Adjusting Roto hardware components may only be carried out by
authorised and qualified personnel.
