“Amrum” gasket
Description Euro-groove/FL Length Surface-fi nish PQ Material no.
Amrum gasket 16/10 mm 4 m Black 80 m 544947
Amrum gasket 16/12 mm 4 m Black 80 m 543439
Amrum gasket 16/10 mm 1.18 m Black 25pcs 544948
Amrum gasket 16/12 mm 1.18 m Black 25pcs 543440
16/10 mm 16/12 mm
“Sylt” gasket
Description
Euro-groove
dimension
Length Surface-fi nish PQ Material no.
Sylt gasket 16 mm 4 m Black 80 m 543428
Sylt gasket 20 mm 4 m Black 80 m 543431
Sylt gasket 16 mm 1.18 m Black 25pcs 543429
Sylt gasket 20 mm 1.18 m Black 25pcs 543432
16 mm 20 mm
“Rügen” gasket
Description
Euro-groove
dimension
Length Surface-fi nish PQ Material no.
Rügen gasket 16 mm 4 m Black 80 m 543422
Rügen gasket 20 mm 4 m Black 80 m 543425
Rügen gasket 16 mm 1.18 m Black 25pcs 543423
Rügen gasket 20 mm 1.18 m Black 25pcs 543426
16 mm 20 mm
Parts list – Roto Eifel TB
Accessories
Gaskets
NOTE!
If gaskets are used in the hardware groove, no
bottom horizontal centre lock can be inserted.
Recommendation: Use the Vertical-Tilter
espagnolette design (see IMO_169_EN).
Shootbolt protrusion
Description Material no.
Shootbolt protrusion for Vertical-Tilter 628290
