Roto NT Power Hinge - Page 47

Subject to change. Roto NT IMO_347_EN_v0
.
July 2014
.
47
Hardware overview
NT hinge side E5 (timber) – Turn-Only / Tilt&Turn hardware
RC1/RC1N (DINEN1627–1630)
4 mm clearance
5
Corner drive 1 V 260272
5a
Corner drive, T&T 1 V 260288
8
Multipart centre lock, bottom horizontal
SRW / mm Size Material no.
600 – 690 200 1 V 296853
691 – 890 400 1 V 296854
891 – 1090 600 1 V 296855
1091 – 1290 600 CON 1 V 337711
200 1 V 296853
1291 – 1400 600 CON 1 V 337711
400 1 V 296854
16
Run-up block 350402
10 mm clearance
5
Corner drive 1 V 566650
5a
Corner drive, T&T 1 V 614456
8
Multipart centre lock, bottom horizontal
SRW / mm Size Material no.
600 – 690 200 CON 1 V 618552
691 – 890 400 1 V 566651
891 – 1090 600 CON 1 V 618553
2)
1091 – 1290 600 CON 1 V 618553
200 CON 1 V 618552
3)
1291 – 1400 600 CON 1 V 618553
400 1 V 566651
16
Run-up block 601500
14
Rebate corner hinge E5, installation dimension 39
12 / 18-9 groove L 451124
R 451123
12 / 18-13 groove L 534596
R 534597
12 / 20-9 groove L 525126
R 525127
12 / 20-13 groove L 534598
R 534599
Rebate corner hinge E5, installation dimension 51.5
12 / 18-9 groove L 456559
R 456560
12 / 18-13 groove L 501521
R 501522
12 / 20-9 groove L 456557
R 456558
12 / 20-13 groove L 501523
R 501524
Rebate corner hinge E5, installation dimension 51.5,
can be screwed on hardware-groove packers
12 / 18-13 groove
1)
L 624316
R 624317
12 / 20-13 groove
1)
L 624318
R 624319
15
Pivot rest E5 12 / 18-9 (-13) without supporting-pins L 449764
Sash weight max. 130 kg R 449763
Pivot rest E5 12 / 18-9 (-13) with supporting-pins L 449796
R 449795
Pivot rest E5 12 / 20-9 (-13) without supporting-pins L 450546
Sash weight max. 130 kg R 450545
Pivot rest E5 12 / 20-9 (-13) with supporting-pins L 450548
R 450547
Application range
Sash rebate width SRW act. sash (T&T) .........600 – 1400 mm
Sash rebate width SRW pass. sash (TU-ON)
.600 – 1400 mm
Sash rebate height SRH .................................1600 – 2600 mm
1)
Sash weight S.kg ...................................................max. 150 kg
Profile-related components
6
Tilt striker threshold set Eifel 13mm
2-sashed centre
730427
7
Tilt striker threshold set Eifel 13mm 534929
Tilt striker threshold set Eifel 9 mm 496779
1) For RC2 SRH 1800–2400mm
2) On application ranges from 891 – 915 mm: Cut off the coupling shoe.
3) On application ranges from 1091 – 1115 mm: Cut off the coupling shoe.
4) By removing the hardware-groove packers the hinge can be used as surface-mounted version.
NOTE!
This document excerpt does not replace the
complete product documentation*. Non-com-
pliance exempts the hardware manufacturer of
his liability.
For all other Tilt&Turn hardware components
refer to:
 CTL_6_EN
* Can be found on www.roto-frank.com
