Roto NT Power Hinge - Page 49

Subject to change. Roto NT IMO_347_EN_v0
.
July 2014
.
49
Hardware overview
NT Power Hinge (timber) – Turn-Only and Tilt&Turn hardware
Basic security
Application range
Sash rebate width SRW ..........................600 – 1600 mm
Sash rebate height SRH ........................1600 – 3000 mm
Sash weight S.kg ........................................ max. 200 kg
4 mm clearance
5
Corner drive 1 V 260272
5a
Corner drive, T&T 1 V 260288
8
Multipart centre lock, bottom horizontal
SRW / mm Size Material no.
1001 – 1600 600 1 V 296855
10 mm clearance
5
Corner drive 1 V 566650
5a
Corner drive, T&T 1 V 614456
8
Multipart centre lock, bottom horizontal
SRW / mm Size Material no.
1001 – 1600 600 CON 1 V 618553
14
Rebate corner hinge Power Hinge L 561988
System 12/18(20)-9 R 561989
Rebate corner hinge Power Hinge L 561986
System 12/18(20)-13 R 561987
14
Rebate corner hinge Power Hinge, height-offset 18 mm L 622833
System 12/18(20)-9 R 622834
Rebate corner hinge Power Hinge, height-offset 18 mm L 622831
System 12/18(20)-13 R 622832
16
Pivot rest Power Hinge for threshold L 561984
R 561985
4
Turn-restrictor335
1)2)
260565
3
Turn-restrictor 335 frame component 264625
Profile-related components
7
Tilt striker threshold set Eifel 13mm 534929
Tilt striker threshold set Eifel 9 mm 496779
1) For Turn-Only sash, installation on top or bottom.
2) For Tilt&Turn sash, installation only on the bottom.
From SRW ≥661mm with T&T corner drive.
From SRW ≥1161mm with T&T corner drive and CL 600 1V.
NOTE!
This document excerpt does not replace the
complete product documentation*. Non-com-
pliance exempts the hardware manufacturer of
his liability.
For all other Tilt&Turn hardware components
refer to:
 CTL_6_EN
* Can be found on www.roto-frank.com
